Digital Four-ring Conductivity Sensor

Short Description:

★ Model No: IOT-485-EC

★ Protocol:  Modbus RTU RS485

★ Power Supply: 9~36V DC

★ Features: Stainless steel case for more durability

★ Application: Waste water, river water, drinking water


  • facebook
  • sns02
  • sns04

Product Detail

This product is the latest digital four-electrode conductivity sensor independently researched, developed, and produced by our company. The electrode is light in weight, easy to install, and has high measurement accuracy, responsiveness, and can

work stably for a long time. Built-in temperature probe, instant temperature compensation. Strong anti-interference ability, the longest output cable can reach 500 meters. It can be set and calibrated remotely, and the operation is simple. It can be widely used in monitoring the conductivity of solutions such as thermal power, chemical fertilizers, metallurgy, environmental protection, pharmaceuticals, biochemistry, food, and tap water.

Main Features:
1.Smart and with standard RS485 Modbus.
2.Independent chip, anti-interference, strong stability.
3.SS316 material for conductivity Sensor housing.
4.Maximum transmission distance 500 meters.
5.High-quality conductivity combination sensor with temperature measurement.
6.Improved conductivity process control and measurement confidence with reduced operational expenditure and process downtime.



Product name IOT-485-pH Online digital water monitoring sensor
parameters Conductivity/TDS/Salinity/Resistivity/Temperature
Conductivity Range 0-10000uS/cm;
TDS Range 0-5000ppm
Salinity Range 0-10000mg/L
Temperature Range 0℃~60℃
Power 9~36V DC
Communication RS485 Modbus RTU
Shell Material 304 Stainless steel
Sensing surface Material Glass ball
Pressure 0.3Mpa
Screw type UP G1 Serew
Connection Low noise cable directly connected
Application Aquaculture, Drinking water,Surface water...etc
Cable Standard 5 meters (customizable)
